| Y系列三相異步電動機 |
| Detailed information |
| |
|
型號 |
功率
(KW) |
額定電流
IN
(A) |
額定轉速
nN
(rpm) |
效率
η
(%) |
功率因數
(cos) |
堵轉轉矩 |
堵轉電流 |
最小轉矩 |
最大轉矩 |
|
額定轉矩
Tst/TN |
額定電流
Lst/TN |
額定轉矩
Tmin/TN |
額定轉矩
Tmax/Tn |
|
同步轉速3000轉/分 rpm |
|
Y80M1-2 |
0.75 |
1.8 |
2830 |
75.0 |
0.84 |
2.2 |
6.5 |
1.5 |
2.3 |
|
Y80M2-2 |
1.1 |
2.5 |
77.0 |
0.86 |
7.0 |
|
Y90S-2 |
1.5 |
3.4 |
2840 |
78.0 |
0.85 |
|
Y90L-2 |
2.2 |
4.7 |
80.5 |
0.86 |
1.4 |
|
Y100L-2 |
3 |
6.4 |
2870 |
82.0 |
0.87 |
|
Y112M-2 |
4 |
8.2 |
2890 |
85.5 |
|
Y132S1-2 |
5.5 |
11 |
2900 |
0.88 |
2.0 |
1.2 |
|
Y132S2-2 |
7.5 |
15 |
86.2 |
|
Y160M1-2 |
11 |
22 |
2930 |
87.2 |
|
Y160M2-2 |
15 |
29 |
88.2 |
|
Y160L-2 |
18.5 |
36 |
89.0 |
0.89 |
1.1 |
2.2 |
|
Y180M2 |
22 |
43 |
2940 |
|
Y200L1-2 |
30 |
57 |
2950 |
90.0 |
|
Y200L2-2 |
37 |
70 |
90.5 |
|
Y225M-2 |
45 |
84 |
2970 |
91.5 |
1.0 |
|
Y250M-2 |
55 |
103 |
|
Y280S-2 |
75 |
140 |
92.0 |
0.9 |
|
Y280M-2 |
90 |
167 |
92.5 |
|
Y315S-2 |
110 |
200 |
2980 |
1.8 |
6.8 |
|
Y315M-2 |
132 |
237 |
93.0 |
|
Y315L1-2 |
160 |
286 |
93.5 |
|
Y315L2-2 |
200 |
356 |
0.8 |
|
型號 |
功率
(KW) |
額定電流
IN
(A) |
額定轉速
nN
(rpm) |
效率
η
(%) |
功率因數
(cos) |
堵轉轉矩 |
堵轉電流 |
最小轉矩 |
最大轉矩 |
|
額定轉矩
Tst/TN |
額定電流
Lst/TN |
額定轉矩
Tmin/TN |
額定轉矩
Tmax/Tn |
|
同步轉速1500轉/分 rpm |
|
Y80M1-4 |
0.55 |
1.5 |
1390 |
73.0 |
0.76 |
2.4 |
6.0 |
1.7 |
2.3 |
|
Y80M2-4 |
0.75 |
2.0 |
74.5 |
2.3 |
1.6 |
|
Y90S-4 |
1.1 |
2.8 |
1400 |
78.0 |
0.78 |
6.5 |
|
Y90L-4 |
1.5 |
3.7 |
79.0 |
0.79 |
|
Y100L1-4 |
2.2 |
5.0 |
1430 |
81.0 |
0.82 |
2.2 |
7.0 |
1.5 |
|
Y100L2-4 |
3 |
6.8 |
82.5 |
0.81 |
|
Y112M-4 |
4 |
8.8 |
1400 |
84.5 |
0.82 |
|
Y132S-4 |
5.5 |
12 |
85.5 |
0.84 |
1.4 |
|
Y132M-4 |
7.5 |
15 |
87.0 |
0.85 |
|
Y160M-4 |
11 |
23 |
1460 |
88.0 |
0.84 |
|
Y160L-4 |
15 |
30 |
88.5 |
0.85 |
|
Y180M-4 |
18.5 |
36 |
1470 |
91.0 |
0.86 |
2.0 |
1.2 |
2.2 |
|
Y180L-4 |
22 |
43 |
91.5 |
|
Y200L-4 |
30 |
57 |
92.2 |
0.87 |
|
Y225S-4 |
37 |
70 |
1480 |
91.8 |
1.9 |
|
Y225M-4 |
45 |
84 |
92.3 |
0.88 |
1.1 |
|
Y250M-4 |
55 |
103 |
92.6 |
2 |
|
Y280S-4 |
75 |
140 |
92.7 |
1.9 |
1.0 |
|
Y280M-4 |
90 |
164 |
93.5 |
0.89 |
|
Y315S-4 |
110 |
201 |
93.5 |
1.8 |
6.8 |
|
Y315M-4 |
132 |
241 |
1490 |
94.0 |
|
Y315L1-4 |
160 |
291 |
94.5 |
|
Y315L2-4 |
200 |
354 |
0.9 |
|
型號 |
功率
(KW) |
額定電流
IN
(A) |
額定轉速
nN
(rpm) |
效率
η
(%) |
功率因數
(cos) |
堵轉轉矩 |
堵轉電流 |
最小轉矩 |
最大轉矩 |
|
額定轉矩
Tst/TN |
額定電流
Lst/TN |
額定轉矩
Tmin/TN |
額定轉矩
Tmax/Tn |
|
同步轉速1000轉/分 rpm |
|
Y80M-6 |
0.55 |
1.8 |
910 |
71.5 |
0.70 |
2.0 |
5.5 |
1.5 |
2.2 |
|
Y90S-6 |
0.75 |
2.3 |
72.5 |
0.70 |
|
Y90 |
1.1 |
3.2 |
73.5 |
0.72 |
1.3 |
|
Y100L-6 |
1.5 |
4.0 |
940 |
77.5 |
0.74 |
6.0 |
|
Y112M-6 |
2.2 |
5.6 |
80.5 |
|
Y132S-6 |
3 |
7.2 |
960 |
83.0 |
0.76 |
6.5 |
|
Y132M1-6 |
4 |
9.4 |
84.0 |
0.77 |
|
Y132M2-6 |
5.5 |
13 |
85.3 |
0.78 |
|
Y160M-6 |
7.5 |
17 |
970 |
86.0 |
2.0 |
|
Y160L-6 |
11 |
25 |
87.0 |
1.2 |
|
Y180L-6 |
15 |
31 |
89.5 |
0.81 |
1.8 |
|
Y200L1-6 |
18.5 |
38 |
89.8 |
0.83 |
|
Y200L2-6 |
22 |
45 |
90.2 |
|
Y225M-6 |
30 |
60 |
980 |
0.85 |
1.7 |
|
Y250M-6 |
37 |
72 |
90.8 |
0.86 |
1.8 |
|
Y280S-6 |
45 |
85 |
92.0 |
0.87 |
1.1 |
|
Y280M-6 |
55 |
104 |
|
Y315S-6 |
75 |
141 |
990 |
92.8 |
1.6 |
1.0 |
|
Y315M-6 |
90 |
168 |
93.2 |
|
Y315L1-6 |
110 |
204 |
93.5 |
|
Y315L2-6 |
132 |
245 |
93.8 |
|
型號 |
功率
(KW) |
額定電流
IN
(A) |
額定轉速
nN
(rpm) |
效率
η
(%) |
功率因數
(cos) |
堵轉轉矩 |
堵轉電流 |
最小轉矩 |
最大轉矩 |
|
額定轉矩
Tst/TN |
額定電流
Lst/TN |
額定轉矩
Tmin/TN |
額定轉矩
Tmax/Tn |
|
同步轉速 750轉/分 rpm |
|
Y132S-8 |
2.2 |
5.6 |
710 |
80.5 |
0.71 |
2.0 |
5.5 |
1.2 |
2.0 |
|
Y132M-8 |
3 |
7.3 |
82.0 |
0.72 |
|
Y160M1-8 |
4 |
9.5 |
715 |
84.0 |
0.73 |
6.0 |
|
Y160M2-8 |
5.5 |
12.7 |
85.0 |
0.74 |
|
Y160L-8 |
7.5 |
17.0 |
86.0 |
0.75 |
5.5 |
|
Y180L-8 |
11 |
24.4 |
730 |
87.5 |
0.77 |
1.7 |
6.0 |
1.1 |
|
Y200L-8 |
15 |
32.9 |
88.0 |
0.76 |
1.8 |
|
Y225S-8 |
18.5 |
39.7 |
735 |
89.0 |
1.7 |
|
Y225M-8 |
22 |
46.4 |
90.0 |
0.78 |
1.8 |
|
Y250M-8 |
30 |
61.6 |
90.5 |
0.80 |
|
Y280S-8 |
37 |
76.1 |
740 |
91.0 |
0.79 |
|
Y280M-8 |
45 |
90.8 |
91.7 |
0.80 |
1.0 |
|
Y315S-8 |
55 |
111 |
92.0 |
1.6 |
6.5 |
|
Y315M-8 |
75 |
150 |
92.5 |
0.81 |
0.9 |
|
Y315L1-8 |
90 |
179 |
93.0 |
0.82 |
|
Y315L2-8 |
110 |
219 |
93.3 |
6.3 |
|
型號 |
功率
(KW) |
額定電流
IN
(A) |
額定轉速
nN
(rpm) |
效率
η
(%) |
功率因數
(cos) |
堵轉轉矩 |
堵轉電流 |
最小轉矩 |
最大轉矩 |
|
額定轉矩
Tst/TN |
額定電流
Lst/TN |
額定轉矩
Tmin/TN |
額定轉矩
Tmax/Tn |
|
同步轉速 600轉/分 rpm |
|
Y315S-10 |
45 |
100 |
590 |
91.5 |
0.75 |
1.5 |
6.2 |
/ |
2.0 |
|
Y315M-10 |
55 |
121 |
92 |
0.75 |
|
Y315L1-10 |
75 |
162 |
92.5 |
0.76 |
|
| |
